Blackmagic Design Mini Converter Audio to SDI 4K

The Blackmagic Design Mini Converter Audio to SDI 4K allows you to embed 4 channels of analogue audio and 8 channels of AES/EBU digital audio into any SDI video connection. It can be used to embed professional audio from devices like analogue decks and audio mixers into SDI video connections to use with SDI decks and routers. It helps add extra audio channels to video converters and maintains the resolution of the original input source.

Blackmagic Design Mini Converter Audio to SDI 4K Key Features:

• Used to embed professional audio from audio mixers or decks into SDI video connections
• Features a 6G-SDI input to accept Ultra HD and DCI 4K resolutions
• Provides four 1/4” audio jack connectors for inputting the audio channels
• Maintains the frame rate and resolution of the original input source
• Supports UHD and DCI 4K resolutions at up to 30 fps
• Can automatically detect and switch between the different signal formats
• Includes a redundant SDI input as an optional backup if the main SDI input is lost
• Includes a redundant SDI input as an optional backup if the main SDI input is lost
• Offers 4:2:2 and 4:4:4 sampling and colour precision
• Supports updates and configuration via USB 2.0 high speed
• Can detect between the SD, HD and 6G-SDI signal formats
• Includes built-in DIP switches to control the settings
• Includes software for Mac OS and Windows computers

Expanded Blackmagic Design Mini Converter Audio to SDI 4K Key Features:

Broadcast Quality Conversion

The Blackmagic Mini Converter produces broadcast-quality conversion for the post-production and AV industry. It keeps all the equipment connected and keeps productions running smoothly. The Mini Converter allows you to embed 4 channels of analogue audio and 8 channels of AES/EBU digital audio into any SDI video signal. The signal conversion over the 6G-SDI connector maintains the frame rate and resolution of the original input source.

Compact Construction

It has a simple, rugged and compact construction, enabling you to use it anywhere. This portabibility means the Mini Converter can be put in equipment racks in the studio or on news trucks. It ensures a reliable 24/7 operation and can also be used outside for live events or sports. It has built-in connections that are easy to access and the mini switches allow you to seamlessly change the settings. The back of the converter has a diagram with switch settings printed so you don’t even need a manual.

Multiple Audio Connections

The Mini Converter maintains the cleanest possible audio signal in sync with the videos in professional broadcast, post and live-production workflows. It lets you separately embed or de-embed the balanced analogue or AES/EBU digital connections. The four 1/4” audio jack connectors can be used for inputting the audio channels, and the 6G-SDI input accepts resolutions up to Ultra HD and DCI 4K.

Easy Control

The built-in function switches in the converter allows you to easily change the settings quickly with no complicated menus to navigate through. The printed diagram on the back of the converter ensures that you don’t have to constantly skim through the manual. Settings can also be controlled via USB using the included software for Mac OS or Windows computers. The USB port can also be used to install firmware updates to the Mini Converter.

What's in the box?

• 1 x Blackmagic Design Mini Converter Audio to SDI 4K
• 1 x 12 V Universal Power Supply with International Socket Adapters
• Limited 3-Year Warranty

FAQs:

What is the power supply required for the converter?

The mini converter requires a 12 VDC power supply with a supported operational range of 12 V – 31 V.

Can it be used to convert audio back to analogue?

This converter is only used to convert analogue signals to digital. It embeds audio onto the video signal and a separate de-embedder can be used to convert audio back to analogue.

Can it detect different signal formats?

This converter automatically detects SD, HD, 2K, UHD, and 4K signals. It detects and automatically switches between the formats.

What is the redundant SDI input for?

It includes a redundant SDI input as a backup option for when the main SDI input is lost. It enables you to run a second SDI cable and comes in handy during outdoor usage where there’s a chance that the cables might get damaged.

What are the environment specifications and how much does it weigh?

This converter weighs around 216 grams and the compact structure allows you to use it anywhere. It is recommended to use the converter at an operating temperature of 0-degree to 40-degree Celsius and 0% - 90% non-condensing relative humidity.
